Railway Plans 1940s-60s
|
|
|
|
item:- Carlisle Library : Map 355 example 1 image:- © Carlisle Library |
click to enlarge |
|
|
Railway plan, station plan, uncolured ?lithograph, Moor
Row Passenger and Goods Station, Whitehaven, Cleator and
Egremont Railway, Moor Row, Egremont, Cumberland, scale
about 1 to 500, from the London Midland and Scottish
Railway, LMS, Surveyor's Department, Euston, London, 1940s?
The folder contains two versions of the station plan. Plan is annotated in coloured ms. Plan 1 shows - railway station buildings including platforms, lamp room, signal box, crane, coal staithes, engine shed, coaling stage, and railway junction, railway bridge, railway milepost, railway houses, etc. Plan2 'RATING PLAN' includes goods shed, joiners shop, carriage shed, fitting shop, small turntable, and has buildings annotated with numbers referring to a schedule. |
||
|
Railway Plans 1940s-60s | |
| map feature:- | north point & up is S (SbyE) & roads & railways | |
| inscription:- |
on the folder
CUM CUMBERLAND / SOUTH A.A / CUM 604-28 / L.M.S. RATES & TAXES DEPT. / EUSTON. |
|
| inscription:- |
plan label, lower right
L.M.S CHIEF ENGINEER'S DEPT / SURVEYOR'S SECTION / MOOR ROW / PASSENGER & GOODS STATION M.P. DEPOT / ... / CHIEF ENGINEER / DATE : - JUNE/46 / ... / C.E's No. R.P. 2329 standard box partly filled in |
|
| inscription:- |
with scale line
SCALE 40 FT. TO 1 INCH (SHRUNK) |
|
| scale line:- | 300+110 feet = 258.1 mm | |
| wxh, folder:- | 23x33.5cm | |
| wxh, sheet:- | 124x49cm | |
| scale:- | 1 to 500 ? (1 to 484 from scale line) | |
|
images:- © Carlisle Library |
|
|
|
||
|
||
